ZE-700 DC ATC New Energy Vehicle Overload Protection
Short Description: The Zing Ear ZE-700 DC ATC New Energy Vehicle Overload Protection is certificated in 3-20 Ampere
| Item Number | ZE-700S-10-MP |
|---|---|
| Input Power | 125VAC/250VAC/50VDC |
| Dielectric Strength | 1500VAC/1 minute |
| Insulation Resistance | >100MΩ |
| Standard Rating | 3-20 Ampere |
| Interrupt Capacity | 125 VAC *1000A, 250 VAC*2000A |
| Temperature | -40~85℃ (40T85) |
| Contact Endurance | 125VAC *150% of rated current-500 cycle |
Overload Protector Details
ZE-700 DC ATC New Energy Vehicle Overload Protection Details
Calibration:
●25℃-100% of rated current-continuously carried
●25℃- Between 101% to 145%- may trip or not
●25℃-150% of rated current- trip within 1 hour
●25℃-200% of rated current- trip within 1 minute
Zing Ear ZE-700 Item Parameter Introduction
Our Advantage
Why choose us?
- Firstly, we are the factory of Zing Ear switch for many years, so we can provide you the high standard quality micro switch products;
- Secondly, we have approved by ISO9001,ISO/TS16949, ENEC, RoHS, REACH, CQC etc. Therefore, we not only can know your requirement professionally, but also we provide you certificates.
- Thirdly, we will help you to solve your problem in the project, because our engineer and sales will service you in the same time.
- What’s more, if you need other electron components, we can help you to buy them and ship with our switch.
